| Part Number | B33-375-2-312-2 |
| Product Number | 150830 |
| UPC | 754473630485 |
| UOM | Roll of 1000 Labels |
| Brand Name | Brady |
| Application | Electrical Labeling, Wire and Cable Labeling |
| Brady Material Number | B-312 |
| Color | White |
| Continuous or Die-cut | Die-cut |
| Diameter as Supplied (imperial) | 0.375 in |
| Diameter as Supplied (metric) | 9.53 mm |
| Dimensions (imperial) | 0.645 in H x 1 in W |
| Dimensions (metric) | 25,40 mm (W) x 16,38 mm (H) |
| Enables Industry Compliance (North America) | MIL-STD-202, UL Recognized |
| Finish | Matte |
| Height (imperial) | 0.645 in |
| Height (metric) | 16.38 mm |
| Industry | Aerospace, Electrical, Voice & data communication |
| Industry Compliance UL | UL924 |
| Label Properties | Heat Shrink |
| Material | Polyolefin |
| Material Properties | Heat-shrinkable |
| Material Type | Polyolefin |
| Maximum Service Temperature (°C) | 135 °C |
| Maximum Service Temperature (°F) | 275 °F |
| Maximum Wire Diameter (imperial) | 0.32 in |
| Maximum Wire Diameter (metric) | 8.13 mm |
| Maximum Wire Gauge | 4 AWG |
| Minimum Service Temperature (°C) | -55 °C |
| Minimum Service Temperature (°F) | -67 °F |
| Minimum Wire Diameter (imperial) | 0.125 in |
| Minimum Wire Diameter (metric) | 3.18 mm |
| Minimum Wire Gauge | 12 AWG |
| Primary Noun, Basic Function.1 | Sleeve |
| Print Technology | Thermal Transfer |
| Printable Sides | Single-Side Printable |
| Printer Compatibility | BBP33, i3300, i5300 |
| Printer and Label Applications | Wire & Cable |
| Printer supply or Pre-printed | Printer supply |
| Quantity per Roll | 1000 |
| Quantity per Row | 2 |
| Recommended Ribbon Series | R4300, R4502S, R5000, R6600, R6700 |
| Recovered Diameter (imperial) | 0.125 in |
| Recovered Diameter (metric) | 3.18 mm |
| Recovered Wall Thickness (imperial) | 0.025 in |
| Recovered Wall Thickness (metric) | 0.64 mm |
| Resistance Properties | Chemical-resistant, Corrosion-resistant, Humidity-resistant, Smear-resistant, UV-resistant, Weather-resistant |
| Ribbon Series | R4300 |
| Roll Width (imperial) | 2 in |
| Roll Width (metric) | 50.80 mm |
| SAP B-Number | B-312 |
| SAP Local Description | B33-375-2-312-2 |
| Service Temperature Range (°C) | -55 °C - 135 °C |
| Service Temperature Range (°F) | -67 °F - 275 °F |
| Shrink Ratio | 3:1 |
| Sleeve Size (imperial) | 0.375 in Dia x 1 in W |
| Sleeve Size (metric) | 9.53 mm Dia x 25.40 mm W |
| Sleeve Slits | Yes |
| Sleeve Width (imperial) | 1 in |
| Sleeve Width (metric) | 25.40 mm |
| Smart Cell | Yes |
| Trade Name | PermaSleeve |
| Vertical Repeat (imperial) | 1 in |
| Vertical Repeat (metric) | 25.40 mm |
| Web Width (imperial) | 3.49 in |
| Web Width (metric) | 88.65 mm |
| Width (imperial) | 1 in |
| Width (metric) | 25.40 mm |
| Wire Diameter Range (imperial) | 0.125 in to 0.32 in |
| Wire Diameter Range (metric) | 3.18 mm to 8.13 mm |
| Wire Gauge Range | 12 AWG - 4 AWG |
| CA Prop 65 Label Warning | WARNING: Cancer - www.P65warnings.ca.gov |
| CA Prop 65 Labeled? | Y |
| Contains CA PROP 65 Substance | Yes Contains-Label required |
| Contains CA PROP 65 Substance (Y/N) | Y |
| Contains CA PROP 65 Warning Type | Cancer |
| Contains Heavy Metal(s) | No - Does not contain |
| EU RoHS Compliance | Pass 2011/65/EU(Pass 2015/863) |
| EU RoHS Compliant | Yes |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
