24" x 4" Brady Label (White on Green) (Card) - 109254
- Part #:
- 109254
Product Description
Brady, 109254, Label, 24" W, 4" H, White on Green
30 Years of Service
Huge Inventory / Fast Shipping
Easy 30 Day Return Policy
Secured Transaction
Laminated B-681 polyester seals in and protects graphics.
| Part Number | 109254 |
| Product Number | 109254 |
| UPC | 754473674861 |
| UOM | Card |
| Brand Name | Brady |
| Adhesive Type | Permanent Acrylic |
| Application | Pipe and Valve Marking |
| Arrow Direction | No Arrow |
| Average Outdoor Durability | 5 to 8 Years |
| Brady Material Number | B-681 |
| Cards or Sheets per Pack | 1 |
| Character Height (imperial) | 3.5 in |
| Character Height (metric) | 88.90 mm |
| Class | Water |
| Color | White on Green |
| Compatible Surface Types | High Surface Energy |
| Country | US, CA, MX |
| Dimensions (imperial) | 4 in H x 24 in W |
| Dimensions (metric) | 60,96 cm (W) x 101,60 mm (H) |
| Enables Industry Compliance (North America) | ANSI A13.1-2007 |
| Height (imperial) | 4 in |
| Height (metric) | 101.60 mm |
| Indoor or Outdoor Use | Outdoor Use |
| Laminated | Polyester Overlaminate |
| Material | Polyester with Polyester Overlaminate |
| Material Type | Polyester |
| Maximum Service Temperature (°C) | 110 °C |
| Maximum Service Temperature (°F) | 230 °F |
| Minimum Application Temperature (°C) | -18 °C |
| Minimum Application Temperature (°F) | 0 °F |
| Minimum Pipe Diameter (imperial).1 | 8 in |
| Minimum Pipe Diameter (metric) | 203.20 mm |
| Minimum Service Temperature (°C) | -40 °C |
| Minimum Service Temperature (°F) | -40 °F |
| Pipe Diameter Range (imperial) | 8 in or larger |
| Pipe Diameter Range (metric) | 203.20 mm or larger |
| Pipe Marker Mounting Style | Self-Adhesive |
| Pipe Marker Style | 1HV |
| Pre-Printed Areas on Label | Pipe Contents |
| Primary Noun, Basic Function.1 | Pipe Marker |
| Printer supply or Pre-printed | Pre-printed |
| Quantity per Card or Sheet | 1 |
| Resistance Properties | Abrasion-resistant, Chemical-resistant, Weather-resistant |
| SAP B-Number | B-681 |
| SAP Local Description | B681 WHT/GRN STYLE IHV FOOD IND. PM. |
| Self-Adhesive Pipe Marker Format | Die-Cut on Cards |
| Service Temperature Range (°C) | -40 °C - 110 °C |
| Service Temperature Range (°F) | -40 °F - 230 °F |
| Text Language | English |
| Text Legend | HOT WATER RETURN |
| Thickness (imperial) | 0.0051 in |
| Thickness (metric) | 0.13 mm |
| Width (imperial) | 24 in |
| Width (metric) | 60.96 cm |
| Contains CA PROP 65 Substance | Yes Contains-Label not req. |
| Contains CA PROP 65 Substance (Y/N) | N |
| Contains Heavy Metal(s) | No - Does not contain |
| DOT Hazardous Material | No = is not a DOT hazardous material |
| EU RoHS Compliance | Pass 2011/65/EU(Pass 2015/863) |
| EU RoHS Compliant | Yes |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
