Permanent Polyester (B-619) is suitable for marking components in control panels, electronic components and circuit boards, faceplates and electrical receptacles.
| Part Number | BCDAT-5-619-5 |
| Product Number | 14042 |
| UPC | 662820140429 |
| UOM | Pack of 5000 Labels |
| Brand Name | Brady |
| Adhesive Type | Permanent Acrylic |
| Application | Asset Tracking, Circuit Board Labeling, Electrical Labeling, General Identification, Component and Equipment Labeling |
| Brady Material Number | B-619A |
| Color | White |
| Compatible Surface Types | High Surface Energy |
| Continuous or Die-cut | Die-cut |
| Dimensions (imperial) | 1.437 in H x 3.9 in W |
| Dimensions (metric) | 99,06 mm (W) x 36,50 mm (H) |
| Enables Industry Compliance (North America) | ASTM B 117, ASTM D 1000, ASTM D 2979, ASTM G 155, CSA Approved, UL Recognized |
| Finish | Matte |
| Height (imperial) | 1.437 in |
| Height (metric) | 36.50 mm |
| Horizontal Repeat (imperial) | 4 in |
| Horizontal Repeat (metric) | 101.60 mm |
| Indoor or Outdoor Use | Indoor Use |
| Label Properties | Heat Resistant, Permanent Adhesive |
| Label/Tape Size (imperial) | 1.437 in H x 3.9 in W |
| Label/Tape Size (metric) | 36.50 mm H x 99.06 mm W |
| Layout | Fan-folded |
| Lines per Inch | 6 or 8 lines per inch |
| Material | Polyester |
| Material Type | Polyester |
| Maximum Service Temperature (°C) | 145 °C |
| Maximum Service Temperature (°F) | 293 °F |
| Minimum Application Temperature (°C) | 10 °C |
| Minimum Application Temperature (°F) | 50 °F |
| Minimum Service Temperature (°C) | -70 °C |
| Minimum Service Temperature (°F) | -94 °F |
| Primary Noun, Basic Function.1 | Label |
| Print Technology | Dot Matrix |
| Printer Compatibility | Dot Matrix Printers |
| Printer and Label Applications | Circuit Board |
| Printer supply or Pre-printed | Printer supply |
| Quantity per Row | 2 |
| Recommended Ribbon Series | R5000 |
| Resistance Properties | Abrasion-resistant, Corrosion-resistant, Humidity-resistant, Smear-resistant, UV-resistant, Weather-resistant |
| Ribbon Series | R2000, R5000 |
| SAP B-Number | B-619A |
| SAP Local Description | BCDAT-5-619-5 |
| Service Temperature Range (°C) | -70 °C - 145 °C |
| Service Temperature Range (°F) | -94 °F - 293 °F |
| Shape | Rectangle |
| Surface | For smooth surfaces |
| Thickness (imperial) | 0.0034 in |
| Thickness (metric) | 0.086 mm |
| Trade Name | DATAB |
| Vertical Repeat (imperial) | 1.5 in |
| Vertical Repeat (metric) | 38.10 mm |
| Web Width (imperial) | 8.9 in |
| Web Width (metric) | 226.06 mm |
| Width (imperial) | 3.9 in |
| Width (metric) | 99.06 mm |
| Contains CA PROP 65 Substance | Yes Contains-Label not req. |
| Contains CA PROP 65 Substance (Y/N) | N |
| Contains Heavy Metal(s) | Unavailable |
| DOT Hazardous Material | No = is not a DOT hazardous material |
| EU RoHS Compliance | Pass 2011/65/EU(Pass 2015/863) |
| EU RoHS Compliant | Yes |
| SDS Safety Data Sheet required | No = MSDS/SDS is not required |
